Cement Lime Machine Gold Ore Fly Ash Grinding Mill Slag Impact Mill 0.5-25ton/H
Description of FAIR superfine grinding pulverizer machine
FAIR superfine grinding pulverizer machine is the new generation of high-fine powder grinding equipment with high-efficiency and closed cycle, which can replace the ball mill. And it can meet different requests under the combined effect of analyzer and fan.
Features of Impact Grinding Mill Advantages
1. The whole plant is a vertical structure of strong systematic characteristic, so it occupies small area. From the crushing of raw material to the grinding and packing, it is an independent production system.
2. Compared with other milling plants, its passing ratio achieves 99%, this is what other mill can not reach.
3. Driving system of main frame adopts airtight gearing and pulley, drives smoothly and operates reliably.
4. Main parts of the whole plant are made of cast and steel of high quality. The technics is so subtly that insures the durability of whole plant.
5. The electric control system is centralized controlled, so the automaticity is high, no people are needed in the operating room.
6. Equip with efficient dust collector, no dust leaking, clean working environment.
Parameter of superfine grinding pulverizer machine
| Model | The roller | The ring | Max Feeding Size (mm) | Discharge Size (mm) | Motor Power (KW) | Capacity (T/h) |
| No. | Diameter (mm) | Height (mm) | Diameter (mm) | Height (mm) |
| YGM65 | 3 | 210 | 150 | 650 | 150 | 15 | 0.613-0.033 | 15 | 0.4-1.8 |
| YGM75 | 3 | 260 | 150 | 780 | 150 | 15 | 0.613-0.033 | 18.5 | 1-3 |
| YGM85 | 3 | 270 | 140 | 830 | 140 | 20 | 0.613-0.033 | 22 | 1.2-4.6 |
| YGM85B | 3 | 270 | 150 | 830 | 150 | 20 | 0.613-0.033 | 22 | 1.2-4.6 |
| YGM95 | 4 | 310 | 170 | 950 | 170 | 25 | 0.613-0.033 | 37 | 2.1-5.6 |
| YGM130 | 5 | 410 | 210 | 1280 | 210 | 30 | 0.95-0.033 | 75 | 3-9.5 |
| YGM160 | 6 | 510 | 230 | 1600 | 230 | 60 | 0.95-0.033 | 185 | 5-22 |
Main parts of FAIR Impact Pulverizer mill machine:
Raymond mill consists of main frame,duct fan,analyzer,cyclone power collection device,bag
duct collector and pipe connection feeder,crusher and so on. to meet clients requirements.
More details we needed for sending you more suitable quotation,
1. What kind of raw material do you want to process?
2. What is the capacity per hour do you need?
3. What is the raw material input size?
4. What is the finished size you required?
Any inquiries of our Hot sale micro powder machine, stone mill, powder grinding mill will be highly regard and we will give you the best quotation ASAP. Your satisfaction is our final an forever pursuit.
Please fill in your need products and your message and do not forget email and/or phone if you like to be contacted.
FAQ:
Q1: Are you trading company or manufacturer?
A: We are crushing and grinding machine manufacturer factory.
Q2: How long is your delivery time?
A: Generally it is 7-10 days if the goods are in stock. Or it is 15-35 days if the goods are not in stock, it is according to quantity.
Q3: What is your payment method?
A: 30% of total prices should be paid by T/T as down payment; 70% balance payment should b paid by T/T before delivery.
Q4: How long is the warrenty of your equipments? Does your company supply the spare parts?
A: The warranty period of equipments is one year. And we will supply the spare parts for you at lowest cost.
Q5: If I need the complete plant can you help us to build it?
A: Yes, we can help you set up a complete crushing line and give you related professional advices as long as you need. We had already build many mining projects in China & Overseas.
